Device agnostic usage with versatile connectivity options, including HDMI, DisplayPort, VGA, and USB 3.0.
Enjoy every detail with advanced ergonomics including pivot, swivel, and height adjustment to provide a greater range of customisable adjustment for maximum comfort. VG2748 is the first monitor to feature a 40° ergonomic tilt angle, which enables you to use the monitor while standing or to have strategic group discussions around the screen.
METICULOUSLY CRAFTED
Striking lines and a small footprint are what make the VG2748 special and the monitor’s minimal modern design fits perfectly into any workspace. Notable design features include a tilted button design, angled bezel edges to direct the user's focus to the centre of the screen, a slanted stand with cable management and an angled metallic carrying handle to make transporting the monitor easier.
vDISPLAY MANAGER
ViewSonic’s proprietary vDisplay Manager software is available for free and allows users to organise and divide their screen into multiple segments. The software also enables users to adjust their monitor settings via the software directly for a more efficient workflow.
CLARITY FROM ANY ANGLE
Enjoy accurate and vivid colours with consistent levels of brightness no matter your vantage point. With SuperClear® IPS panel technology, the monitor delivers the same image quality whether you are looking at the screen from above, below, the front, or the side.
VERSATILE STAND DESIGN
VG2748's versatile stand is equipped with cable management design features that keep your workspace neat and free of cable clutter. A carrying handle sits at the top of the stand for stability when relocating the monitor.
4-STEP ASSEMBLY
VG2748 utilises a new Quick Release stand design which lets you attach/detach the panel with the push of a button. Can be assembled entirely by hand in four simple steps:
CONNECTION FLEXIBILITY
HDMI, DisplayPort, VGA, and USB 3.0 inputs enable you to connect an array of devices to VG2748.
DUAL SPEAKERS
Designed with dual integrated speakers, VG2748 accents its incredible screen performance with immersive stereo sound for a complete multimedia experience.
VESA COMPATIBILITY
Mount the monitor exactly to your liking by utilising the monitor’s 100 x 100mm VESA compatible design.
LOW ENERGY CONSUMPTION
VG2748 has been designed with energy efficiency in mind. With certification from Energy Star and EPEAT, VG2748’s Eco-mode consumes less power, resulting in a smaller carbon footprint and reduced office overhead costs.
ENVIRONMENTALLY FRIENDLY PACKAGING
Designed with the environment in mind, the packaging for the VG48/VG55/VG55-2K series is made with up to 80% recyclable and paper-based materials instead of hazardous EPS (polystyrene).
FLICKER FREE
Traditional LED screens flicker over 250 times per second, at a frequency that is not perceivable to the naked eye. This can cause dryness, headaches and eye sensitivity over long usage periods. ViewSonic has integrated a Flicker Free backlight circuit to alleviate this, resulting in more comfortable display usage.
BLUE LIGHT FILTER
Radiation from the blue-violet light spectrum is harmful to our eyes. ViewSonic's Blue Light Filter moderates blue light output, reducing eye irritation and fatigue for improved viewing comfort.
DISPLAY
Monitor Size: 27”W (27” Viewable) LCD monitor
Panel Technology: SuperClear® IPS TFT LCD
Resolution: FHD 1920 x 1080
Display Area: 597.9(H) x 336.3(V) mm
Aspect Ratio: 16:9
Brightness: 300 cd/m2 (Typ.)
Contrast Ratio: 1000:1 (Typ.)
Dynamic Contrast Ratio: 50,000,000:1
Viewing Angles: 178 degrees (Typ.) / 178 degrees (Typ.)
Response Time: GTG: 5ms (Typ.)
Pixel Size: 0.311 (H) x 0.311 (W) mm
INPUT SIGNAL
Frequency: Analog: Fh = 24 ~ 82KHz ; Fv = 50 ~ 75Hz
Digital: Fh = 24 ~ 82KHz ; Fv = 24 ~ 75Hz
Sync: Separate Sync / Composite Sync / Sync on Green / TMDS / PCI-E
COMPATIBILITY
PC: Windows 7, Windows 8, Windows 8.1, Windows 10 certified
Mac®: Power Mac tested
CONNECTOR
Input: VGA x 1, HDMI x 1 (v1.4 compatible), DisplayPort 1.2 x 1
AUDIO
Speaker: 2W x 2
USB
Upstream: USB 3.0 Type B x 1
Downstream: USB 3.0 Type A x 4
POWER
Power: 3-pin plug (CEE22) x 1
Voltage: AC 100-240V (Universal); 50/60Hz
Consumption: 29.15W
Optimize: 23.06W
Conserve: 18.50W
ERGONOMICS
Tilt: 40 ~ -5 degrees
Swivel: +/-60 degrees
Pivot: +/-90 degrees
Height Adjust: 0~130 mm
SPECIAL FEATURES
Eye Care: Blue light filter, Flicker Free
WALL MOUNT
VESA®: 100mm x 100mm
OPERATING CONDITIONS
Temperature (º F / º C): 32°F to 104°F (0°C to 40°C)
Humidity: 20% to 90% (no condensation)
DIMENSIONS (W X H X D) (MM)
Physical with stand (mm): 620.7mm (W) x 537.2mm (H) x 202.2 mm (D)
Physical without stand (mm): 620.7 mm (W) x 366.1mm (H) x 51.1 mm (D)
Packaging (mm): 692 mm (W) x 430 mm (H) x 218 mm (D)
WEIGHT
Net with stand: 7.3kg
Net without stand: 4.9kg
Gross: 10.1 kg
REGULATIONS
cTUVus, FCC-B, ICES003, Energy Star 8.0, EPEAT Bronze, CEC, MX-CoC, Mexico Energy, CE, CE EMC, CB, RoHS, ErP, REACH, WEEE, TCO 8.0, EAC, UkrSEPRO, GS
PACKAGE CONTENTS
LCD Display
Power Cable (1.8m)
DP to DP Cable (1.8m)
USB3.0 Upstream Cable (1.8m)
Quick Start Guide
